    Horizontal Laminar Air Flow Cabinet / Class 100 Clean Air Laminar Flow Unit

    Ask Lasest Price
    Brand Name : Zhisheng
    Model Number : ZS-SP-1900
    Certification : ISO9001
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 100 set per month
    Delivery Time : about 15 days upon receipt of deposit
    • Product Details
    • Company Profile

    Horizontal Laminar Air Flow Cabinet / Class 100 Clean Air Laminar Flow Unit

    Horizontal Laminar Flow Air Cabinet/ Laminar Flow Unit In Class 100


    Clean bench.pdf


    ISO 9001 Certified


    Description:


    Laminar flow cabinet / clean bench is a specialized equipment to bring high cleanliness to partial area.

    The bench top material: Stainless steel 304

    Framework: High quality cold rolled steel plate with powder coated or stainless steel


    Application:

    It is widely applied to industries like electronics, instrument, apparatus, National Defense, medical care and pharmacy etc.


    Optional accessory:

    1. Hepa filter or ULPA filter

    2. Static-free top or stainless steel top, the top can be punched

    3. Framwork is used of common cold rolled steel plated with powder coated or stainless steel.

    4. Domestic or EBM fans

    5. Pressure gauge


    Standard size and specification:


    ModelZS-SP-900ZS-SP-1300ZS-SP-1600ZS-SP-1900
    Dimension (W x D x H) mm900x850x14801300x850x14801600x850x14801900X850X1480
    Size for working area (W x D x H)mm820x550x6101220x550x6101520x550x6101820X550X610
    Suitable people1 man1-2 men2-3 men3 men
    Size of HEPA filter(mm)820x610x691220x610x69915x610x69 610x 610x69915 x 610 x 69
    QTY of HEPA filter (pcs)111/12
    Noise≤58dB≤58dB≤58dB≤62dB
    Blow power320W320W370W320W
    Fluorescent lamp20Wx120Wx120W x 230Wx2
    Material of Bench topSUS304
    Produce/Inspection standardUS Federal standard 209E
    Air velocity0.35-0.6m/s
    Voltage380V/50Hz/3Ph
    VoltageAC 380V/50Hz/3PH, 220V/50Hz/1Ph or 110V/60Hz/1Ph
    Cleanliness Class100 class (US Federal standard 209E)
    Efficiency99.99% @0.3μm

    Horizontal Laminar Air Flow Cabinet / Class 100 Clean Air Laminar Flow Unit


    Note: Customized size and specification can be acceptable.


    Testing in factory:


    All of equipment will be individually tested for safety and performance in accordance with international Standards before shipment. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.


    Testing before shipment:

    1. Appearance inspection

    2. Electrical safety tests

    3. Air wind speed testing

    4. Function testing


    Warranty:


    The warranty of our equipment is for 1 year, but excluding consumable parts and accessories.

    All equipment is shipped with a comprehensive use’s manual with testing report.

    Additional IO/OQ/GMP document is available upon request.

    Contact our sales representative for specific warranty details or document request.


    Replacement parts:

    1. HEPA filter: It should be changed in half or one year once.

    2. Pre filter: It should be changed in 3-6 month once.


    Why you choose ZHISHENG Company ?


    Professional service:


    Fast reply in 12 hours if we receive any inquiry or request from customer

    • Familiar with equipment.


    Delivery time:

    Production period:15-30days

    • Shipping notice or insurance for you after the goods is shipped.


    After sales service:


    We respect your feed back after receive the goods.

    • We provide 1 year warranty after goods arrive.

    • We promise all spare parts available in lifetime use.

    • We care of your complain within 48hours.


    Payment Term:

    30% prepayment by T/T at order, the balance of payment before shipment.
